YXL10SP
10" Powered Subwoofer
In-store pickup only. We don't ship this item. Order online and collect it free in store, usually ready within 24 hours. Pickup details
We’ll email you once, when it’s available.
- 15-day returns. Return policy
- Warranty: 2 years · 10 years on wooden enclosure components. Full terms
Is it right for you?
The most compact YXL powered sub: a 10-inch woofer and 1000 W peak, sized to add bass in smaller venues without overwhelming the mix.
Great for
- Adding bass to YXL10P or YXL12P tops
- DJ sets and bands in smaller venues
- Small rigs that have to travel light
Description
The YXL series is Yorkville Sound's most affordable and versatile speaker lineup, and the YXL10SP is the lightest, most compact YXL powered subwoofer.
Featuring 1000 watts of peak power and three selectable voicing modes, it provides powerful bass reinforcement that won't overwhelm the mix in smaller venues. It was designed to be an ideal accompaniment for YXL top boxes, and can be paired with any full-range speaker.
Key Features
- 1000 W peak power (500 W program)
- 10" woofer with 2.4" voice coil
- 2x XLR / 1/4" combo-jack inputs, 2x XLR link outputs
- Advanced DSP with component protection
- Punch, Smooth and Deep voicing modes
- 12 mm plywood enclosure with pole mount adapter
- 125 dB peak SPL, 50 Hz–100 Hz frequency response
Specifications
- System type: powered subwoofer
- Power rating: 1000 W peak (500 W program), Class D
- Max SPL: 125 dB peak
- Frequency response: 50 Hz–100 Hz
- LF driver: 10" with 2.4" voice coil
- Inputs: 2x combo jack (XLR / 1/4"); 2x XLR link outputs
- Controls: master level; Punch, Smooth and Deep voicing modes
- Limiter: multiband excursion, RMS and rail; speed-controlled fan cooling
- Handle: 1 (top); pole mount adapter on the side
- Enclosure: 12 mm plywood, painted
- Dimensions (D x W x H): 18.3" x 12" x 18.8" (47 x 31 x 48 cm)
- Weight: 34.5 lb (15.6 kg)
Pairs well with
Make it work
What you need with the YXL10SP
You also need
-
Top speakers. The sub plays only 50 Hz to 100 Hz; set YXL tops to sub mode.Pick one
-
A mixer or DJ controller with XLR outputs to feed the sub.Pick one
-
Two XLR cables from the mixer's left and right outputs into the sub's two combo inputs.
2 × CMI-100 Quad Microphone Cable25 ft
$89.90$44.95 each
-
Two XLR cables from the sub's link outputs to the tops, one per top.
2 × CMI-100 Quad Microphone Cable10 ft
$53.90$26.95 each
Works with
See it in a full setup
- Create your flowStart with the YXL10SP DJLive Venue
See it in action
